R&D EQUIPMENT
DC SOURCE
DC-source provides DC input voltage
OSCILLOSCOPE
Analyze and verify whether the design parameters of the sample are reasonable
LIGHTNING STRIKE TESTER
Test whether the design sample meets the lightning strike standard requirements, such as 4KV, 6KV, 8KV, etc
LOAD TESTER
Test whether the voltage and current of the sample meet the requirements. It includes testing OCP
LOAD TESTER-2
Test whether the voltage and current of the sample meet the requirements. It includes testing OCP
OSCILLOSCOPE 2
Analyze and verify whether the design parameters of the sample are reasonable and test the ERP energy efficiency. Meanwhile, test sample ripple VPP and noise.
ESD TEST DEVICE
Test samples for compliance with ESD design requirements, such as 8KV contact discharge, and 15KV air discharge.
EMI TEST DEVICE
Simulation test whether the sample conduction conforms to design standard EN55032 /EN55035/FCC part 15B
EMI TEST RECEIVER
Simulation test whether the sample conduction conforms to design standard EN55032 /EN55035/FCC part 15B
QUALITY CONTROL DEPARTMENT
Hazardous material management policy
CONSTANT TEMPERATURE AND CONSTANT HUMIDITY
Test product performance. Such as whether it will get damaged in high and low temperatures and hot and cold alternating conditions.
ROLL RELIABILITY TESTER
Reliability test. It is mainly used to test whether electronic components are loose
STEEL BALL IMPACT TESTER
Test plastic housing to see if it will crack under external force
ROSH TEST DEVICE
Test the materials whether meet the regulations of Rohs 2.0 and REACH
BENDING TEST
Mainly test is whether the DC wire will have poor contact or other damage during use.
SALT TEST MACHINE
Mainly test hardware whether oxidation rust, corrosion, and so on. Such as: AC shrapnel, AC pin, DC Plug, etc
PLUG TESTING DEVICE
Test the Plug whether good contact with the socket
HIGH-TEMPERATURE TESTER
Test whether the product will work properly in high and low-temperature working environments
VIBRATION TESTING DEVICE
Simulation of whether the product and packaging will be damaged during transportation
DC POWER SUPPLY
Test whether the electrolytic capacitor works properly
LCR TESTER
IQC inspects transformer or inductance
OQC WITHSTAND VOLTAGE TESTER
HV sampling inspection before shipment
RAW MATERIAL QUALITY CONTROL AREA
Raw materials disassemble area---material quality control
DROP TESTING DEVICE
Test finished housing whether cracking or not
TENSILE TEST
Test the SR tolerance of the cable
PRODUCTION LINE
DIP LINE
Plug-in operation according to working instructions and sample acknowledgment
WAVE SOLDER
Weld components on PCB board in batches
AI&SMT LINE
Paste SMD components on PCB by red glue process (completed by SMT mounter), and insert vertical components on PCB by AI machine
MANUAL DIP LINE A
Plug-in operation according to working instructions and sample acknowledgment
AUTOMATIC PRODUCTION LINE
Includes burn-in, HV, and ATE integrated testing (voltage, current, efficiency, ripple, OCP, SCP, etc.)
PLASTIC INJECTION LINE
Production of the plastic housing
MOLD PRODUCTION LINE
Make new mold
